VOD
Application
VOD Series vacuum oil dehydrator is specially designed to remove trace moisture in various industrial oils such as
lubricant oil, hydraulic oil, turbine oil, freezing oil and other lubricant oils. It can also be used to remove water in edible oils such as used cooking oil, vegetable oil, coconut oil, palm oil, olive oil, olive oil, soybean oil, sesame oil and corn oil, etc. The machine can be made of two kinds of material: stainless steel and carbon steel.
Technical parameters
Model |
VOD |
10 |
20 |
30 |
50 |
75 |
100 |
125 |
150 |
200 |
250 |
300 |
Flow Rate | L/min | 10 | 20 | 30 | 50 | 75 | 100 | 125 | 150 | 200 | 250 | 300 |
Working Vacuum | MPa | -0.070~0.099 | ||||||||||
Working Pressure | MPa | ≤0.5 | ||||||||||
Working Temperature | ℃ | 40-70 | ||||||||||
Power Supply | 380V,50HZ,3Phase(Customizable) | |||||||||||
Residual Water | ≤20ppm | |||||||||||
Impurities | ≤1micron | |||||||||||
Residual Gas | ≤0. 1% | |||||||||||
Cleanliness Degree(NAS) | ≤6 | |||||||||||
Cleanliness Degree | ≤15min | |||||||||||
Working noise | dB(A) | 65 | ||||||||||
Heating power | KW | 9 | 15 | 24 | 30 | 48 | 60 | 72 | 90 | 108 | 115 | 120 |
Total power | KW | 10.5 | 17 | 26 | 33 | 52 | 66 | 78 | 98 | 118 | 125 | 132 |
Inlet/outlet | mm | 19 | 25 | 32 | 32 | 44 | 48 | 50 | 50 | 58 | 63 | 65 |
Weight | Kg | 290 | 350 | 420 | 500 | 620 | 750 | 950 | 1150 | 1200 | 1350 | 1450 |
Dimensions(mm) | L | 1180 | 1230 | 1250 | 1300 | 1550 | 1650 | 1700 | 1750 | 2100 | 2150 | 2200 |
W | 750 | 820 | 850 | 920 | 950 | 1000 | 1100 | 1100 | 1200 | 1225 | 1250 | |
H | 1100 | 1150 | 1200 | 1350 | 1400 | 1500 | 1680 | 1700 | 1900 | 1925 | 1950 |
